1可以從它的制作工藝及外觀來鑒別。它直接體現出公司對產品的質量重視，工藝及外觀好的產品質量自然會好一點。

It can be identified from its manufacturing process and appearance. It directly reflects that the company attaches importance to the quality of products, and the quality of products with good technology and appearance will be better.

2可以根據它的工藝設計及使用材料來鑒別。設計是否合理應根據選用材料來定，材料的好壞直接影響產品的質量。同規格的材料產地不一樣，鑒別旋轉噴淋清洗機換能器好壞的方法，質量也就會有差別。

It can be identified according to its technological design and materials. Whether the design is reasonable or not should be determined according to the selection of materials. The quality of materials directly affects the quality of products. The same specifications of the material origin is not the same, identify rotary spray cleaning machine transducer good or bad method, the quality will be different.

3參數檢測。檢測換能器參數是否跟電箱參數匹配，是否能達到理想效果。

3. Parameter detection. Test whether the transducer parameters match with the electrical box parameters, and whether the ideal effect can be achieved.

4上機試驗。

4. Computer test.

①、功率輸出試驗。它能檢測出換能器與電箱的匹配情況，同時可以反應出電箱及換能器負載功率輸出的大小，非人為調節電流大小的前提下，多次試驗對比下，鑒別旋轉噴淋清洗機換能器好壞的方法，電流越大，如工作效果越好，說明功率輸出越強（電流大小只能反應輸出效率，并不代表設備功率大小）。

① Power output test. It can detect the matching condition of the transducer and the electric box, and can reflect the power output of the electric box and the transducer load. On the premise of non-human adjustment of the current, the method to identify the transducer of the rotary spray cleaning machine is compared with many tests. The higher the current, the better the working effect, indicating the stronger the power output (the current can only reflect the output efficiency, It does not represent the power of the device).

②、穩定性試驗（模擬老化試驗）；帶上設備額定負載檢測電箱及換能器的功率輸出穩定性。

② Stability test (simulated aging test); Test the power output stability of the electric box and transducer with the rated load of the equipment.

③、超負荷運作測試；測試產品質量的穩定性及壽命。此項檢測只需帶上額定負載連續不間斷運行8小時就OK。

③ Overload operation test; Test the stability and life of product quality. This test only needs to take on the rated load and run continuously for 8 hours.

全自動超聲波清洗機的清洗流程以及特點，壓鑄件、壓鑄鋁根據其清洗特性均可設計成使用單梁多臂機械手搬運工件的全自動超聲波清洗機。該類型自動超聲波清洗設備是用于五金壓鑄零件表面油脂、雜質等清洗并進行烘干的專用設備，清洗過程由可編程控制器控制全自動完成。全自動超聲波清洗機的清洗流程以及特點，設備的主要結構包括清洗槽體、儲液箱體、機械手傳送機構、過濾循環過濾系統、超聲波裝置、自動恒溫加熱系統，隧道式烘干線、電器控制系統。

According to the cleaning process and characteristics of the automatic ultrasonic cleaning machine, die-casting parts and die-casting aluminum can be designed to use a single beam multi arm manipulator to carry the workpiece. This type of automatic ultrasonic cleaning equipment is a special equipment for cleaning and drying the surface grease and impurities of metal die-casting parts. The cleaning process is controlled by programmable logic controller. The main structure of the equipment includes cleaning tank, liquid storage box, manipulator transmission mechanism, filtering circulation filtering system, ultrasonic device, automatic constant temperature heating system, tunnel drying line and electrical control system.

設備的運行過程是由人工將放好的工件的托盤置入專用洗籃，經機械手提清洗籃依次進行超聲波清洗、超聲波清洗、漂洗、過水、風切、熱風干燥后自動送出。全自動超聲波清洗機的清洗流程以及特點，整機為封閉式結構，裝有可拆卸的觀察檢修門，便于日常維護操作。

The operation process of the equipment is that the tray of the placed workpiece is manually put into the special washing basket, and then automatically sent out after ultrasonic cleaning, ultrasonic cleaning, rinsing, water passing, air cutting and hot air drying by the mechanical hand-held washing basket in turn. The cleaning process and characteristics of the automatic ultrasonic cleaning machine, the whole machine is closed structure, equipped with detachable inspection door, convenient for daily maintenance and operation.

使用浦項SUS304L不銹鋼通過氬弧焊焊接槽體、結構支架及機器外封板，外觀精美、漂亮大方、經久耐用；

POSCO SUS304L stainless steel is used to weld the tank body, structural support and machine outer sealing plate by argon arc welding. The appearance is exquisite, beautiful and durable;

控制整機運行，機械手提清洗籃做上下及橫向移動，左進右出，實現高度機械自動化；

Control the operation of the whole machine, the mechanical hand-held cleaning basket moves up and down and horizontally, left in and right out, realizing a high degree of mechanical automation;

上下料口及各槽各位均設有自動感應設備，防止機器運行發生清洗籃碰撞事件發生；

Automatic induction equipment is set at the loading and unloading port and each slot to prevent collision of cleaning basket during machine operation;

過載保護安全電路設計系統，過載之后三色燈自動發出預警信號，保護電路及操作人員生產安全；

Overload protection safety circuit design system, after overload, three color light automatically sends out warning signal to protect the safety of circuit and operators;

剎車渦輪減速電機采用意大利進口產品，剎車定位精準，安全可靠，性能穩定；

The brake turbine reducer motor is imported from Italy, with accurate brake positioning, safe and reliable performance;

自動液位控制添加補償功能，保證各槽各級水液及工件的清潔；

Automatic liquid level control adds compensation function to ensure the cleanness of water and workpiece at all levels in each tank;

可根據各類五金壓鑄件產品的特性定制專用非標設備。

Special non-standard equipment can be customized according to the characteristics of various kinds of metal die casting products.
